Hood BOSCH DWK67CM20

Technical specifications:

• E White Hood
• 60 cm
• Device color: White
• Glass plate: white transparent glass
• Two operating modes: exhaust air or air circulation
• With recirculation, operation without exhaust into a chimney is possible
• For recirculated extraction, a recirculation kit (accessory) is required.
• For wall mounting
• Easy installation system
• TouchControl sensor control (3 power levels with additional intensive level), LED display
• 2 suction zones: front and bottom
• Intensive level with automatic switching on every 6 minutes
• Inner frame - easy to clean
• High-power dual-channel fan
• Energy-efficient capacitor motor
• Workplace lighting with 2 x 1.5 W LED modules
• Illumination intensity: 100 lux
• Color temperature: 3500 K
• Side suction
• The filter cover is made of glass.
• Metal grease filter, suitable for cleaning in a dishwasher
• Capacity according to EN 61591 ø 15 cm:
  at the highest normal rate 416 m³/h;
  at intensive degree 700 m³/h
• Air extraction capacity according to EN 61591 max. 416 m³/h
• Maximum capacity 416 m³/h according to EN 61591
• Capacity (air extraction) according to EN 61591:
  at the highest normal level 416 m³/h; at the intensive level 700 m³/h
• Noise level according to EN 60704-3 and EN 60704-2-13 at the highest normal level: 58 dB(A) re 1 pW (45 dB(A) re 20 µPa sound pressure)
• Noise level according to EN 60704-3 and EN 60704-2-13:
  at highest normal level: 58 dB(A) re 1 pW (45 dB(A) re 20 µPa sound pressure);
  at intensive level: 67 dB(A) re 1 pW (54 dB(A) re 20 µPa sound pressure)
• For pipe Ø 150 mm (Ø 120 mm attached)
• Max. capacity: 700 m3 /h
• Extraction in recirculation mode:
  max. standard level: 388 m³/h; intensive: 557 m³/h
• Noise level in recirculation mode:
  max. in standard mode: 66 dB(A) re 1 pW (53 dB(A) re 20 µPa sound pressure)
  Intensity level: 75 dB(A) re 1 pW (62 dB(A) re 20 µPa sound pressure)
• Power supply: 263 W
• Dimensions of the unit when air is removed (HxWxD): 928-1198 x 590 x 499 mm
• Dimensions with recirculation with chimney (HxWxD): 988 - 1258 x 590 x 499 mm
• Dimensions in recirculation without chimney (HxWxD): 452 mm x 590 x 499 mm

Warranty: 24 months
