Modern design and compact construction
Tronic 5000 is only 11 cm deep and with its excellent design fits perfectly into any interior. The high-quality materials of the water heater guarantee a long service life.
Various comfort and safety features
The Tronic 5000 is the perfect match for your requirements. The control panel with rotary switch and printed symbols allows you to set various parameters, such as the desired temperature or select one of 4 applications between 20 °C and 60 °C: hand washing, showering, bathing and rinsing with different temperatures. The child lock can be activated by the installer and protects against scalding. The boiler is vented automatically by an air bubble detector. All safety functions have been tested and approved for use by an independent institute of the Association of German Electrical Engineers.
Preparing for connectivity
The boiler can be easily connected via a dongle (available as an optional accessory) to the Bosch HomeCom Easy app. With the Bosch HomeCom Easy app, the water boiler can be controlled from anywhere. The front panel of the appliance can be easily removed to install a dongle for the WLAN connection.
Ideal replacement solution
The transparent back panel of the Tronic 5000 makes it easy to replace old water heaters, even from other brands, by using existing openings. This avoids damage to the home and ensures quick and easy installation.
Easy installation with Clickfix plus ®
The device is installed in just 3 steps. Colored markings on the frame indicate the connection points. This means that the Tronic 5000 can be installed in the shortest possible time.
- Rated power: 11/13kW
- At nominal performance, the device has a capacity of up to 7.1 l/min.
- Flow pressure at switch-on (without flow limiter): 0.4 bar
- Possibility to block the maximum DHW temperature C 42 / 48 / 53 (jumper adjustment)
- Electrical connection: 400 V Protection class (EN 60529): IP25 IP protection class (EN 61140): I Fuse: 32 A
- Max. working water pressure bar 10
- Sound power level indoors: 15 dB (A)
- Dimensions:
- Height 484 mm
- width 236 mm
- depth 106 mm
Warranty: 24 months
