FIRE RESISTANT CONSOLE D68MM

FIRE RESISTANT CONSOLE D68MM

by F-tronic
€18,90 - €18,90
€18,90
€18,90 - €18,90
€18,90
SKU DGT0390765
Ships within 7 business days Please note that quantities are limited and dynamic. At the time of ordering, the item may be out of stock. We will notify you in a timely manner in the event that we are unable to fulfill the order.

Избери период за изплащане и виж месечната вноска

Месечна вноска Обща сума за плащане ГПР Лихва Банка

Description

The triathlon among the socket boxes.
Fire protection, sound insulation, airtightness.
DIBt Z-19.21-2283
ETA-18/0628
Reverse installation and conversion possible.
Tested for up to 5x combinations.
Light wall:

  • fire resistance class EI120
  • fire resistance class EI30 to EI60 without insulation wool

Laminated timber wall:

  • fire resistance class EI90

Shaft wall:

  • up to EI90

Features:

  • Milling hole diameter: Ø 68 mm
  • Suitable for sheet thickness: 5-40 mm
  • Cable entry 3x1.5²: 2
  • Cable entry 5x1.5²/3x2.5²: 2
  • Max. cross-section: 2.5 mm²
  • Pipe inlet: 2x ≤ M25
  • Depth: 62 mm
  • Installation type: HW
  • Socket material: PP/TPE-S
  • Halogen-free
  • Degree of protection (IP): IP30
