Description
THE SMALLEST CHARGING STATION ON THE MARKET!
EVPoint EV7 is a truly special charging station. The compact dimensions of the charger make it an easy and convenient solution for charging electric vehicles and plug-in hybrids in home and public settings. Its successful use in public settings has made this station, manufactured in Bulgaria, one of the most sought-after chargers for hotels, office buildings, shopping centres and car showrooms. This is not a typical charging station. Adding electrical energy to the vehicle's battery is the main task of every station. However, with the development of software, more and more convenient extras are being added to chargers, which simplifies daily charging and proper monitoring of all processes. EV7 is exactly such a device – modern.
Thanks to built-in internet connectivity (3G, 4G, Wi-Fi and Ethernet), the station allows remote control and real-time monitoring from the comfort of the EVPoint mobile app. The internet connection also allows remote receipt of updates that improve the device's operation, as well as online diagnostics in case of a problem or fault. The station itself has its own web interface for configuration, monitoring and diagnostics.
Through the supported OCPP 1.6 protocol, the station can be connected to any platform that works with the same protocol. This is especially important when the station is used for public charging. Operator platforms, such as the one at evpoint.bg, provide the ability to access and manage your stations, as well as charge customers for charging sessions.
Smart charging settings
The internet connectivity of the stationary station allows smart configuration of your charging, whereby the processes can run on a set operating mode during hours when electricity is at a lower price / tariff. From the comfort of your smartphone and thanks to the EVPoint mobile app, you can set the minimum and maximum amount of electricity you want to charge, the time window in which the process should run, and save a daily schedule so that you don't have to repeatedly enter the desired parameters. Through the mobile app, the station will carry out your set requirements, which guarantees maximum efficiency of every charging session with the EV7 station.
Choosing the charging speed
The charging rate can also be controlled. The single-phase charging station can charge at the amperage you specify up to 32A – 7.4 kW. Given the widely used single-phase on-board chargers in electric vehicles on the market at present, the EV7 stands out as one of the best-optimised chargers in terms of functionality and charging capabilities. Thanks to its compact size, the station can also be used as a mobile charger, and the option to select charging power allows adjustment to the optimal characteristics of the electricity source.
When installed at a public location where other smart stations are already present, the EVPoint EV7 can monitor instantaneous consumption and regulate the charging power of all devices so that the grid is not overloaded, while the charging process is not interrupted. This function is known as Dynamic Load Management.
Electric vehicle 3.7 kW 7.4 kW
HYUNDAI IONIQ ELECTRIC (28 kWh) 7.5 hours 4 hours
PEUGEOT E-208 (47.5 kWh) 13 hours 6.5 hours
BMW I3 (42.2 kWh) 11 hours 5.5 hours
SKODA ENYAQ IV (52 kWh) 14 hours 7 hours
Monitoring charging sessions in real time
A convenient feature of the EVPoint mobile app combined with the charging station is the ability to remotely monitor charging sessions in real time. This way you can see the instantaneous power, change the previously set parameters, or stop the charging if necessary. Charging history Every charging session started through the application is recorded and stored in your charging history. From this section, you can generate statistics for a specific period and analyze the electricity consumption used for the vehicle from your home. RFID and Plug & Charge If you use the charger for charging at a public location, you can enable the option to start charging via an RFID card. This way, anyone who has a specially authorized card for your station will have access to it. When used at home, or if the station is installed at a location where only you have access, the device can be set to the so-called "Plug & Charge" mode - you connect the cable and charging begins. Manufacturer: EVPoint Model: EV7 Maximum power: 7.4 kW (single-phase) Rated voltage: 230 V AC (for single-phase connection) Connection to the electric vehicle: Cable with Type 1 connector J1772 Cable length: 5 meters (option to order other lengths - 3, 8 and 10 meters) Number of phases: single-phase, 1 x 32A (7.4 kW) Communication protocol: OCPP 1.6J Communication modules: WLAN: 802.11 b/g/n/e/i (2.4GHz); Bluetooth: BT4.2; Ethernet; Authorization method: via the EVPoint mobile application, RFID card, Plug & Charge Enclosure material: Plastic Protection degree: IP54 protection against environmental impact; Residual current protection: built-in Class B, RCD DC< 6mA; grounding conductor check; +- 207v-253v check Electricity meter: Built-in electricity meter Mounting: Wall-mounted Operating temperature: -25 ° C + 60° C Color: black Dimensions: 187 x 122 x 90 mm - The smallest SMART station in the world. Warranty: 60 months: 24 months (standard) + 36 months (* extended warranty) Weight: 3.500 kg. (with cable) Origin: Bulgaria
