| Marketing description |
| AXIS M5525-E is a great deal. The affordably priced camera is equipped with the kind of incredible features normally expected of high-end cameras. It is especially suitable for shops, schools, building lobbies and other open spaces, both indoors and outdoors. |
| Product features |
-
Better value for your money
AXIS M5525-E is an excellent deal. The affordably priced camera is equipped with the kind of incredible features normally expected of high-end cameras. It is especially suitable for shops, schools, building lobbies and other open spaces, both indoors and outdoors.
-
Don't miss a thing
HDTV 1080p resolution, 10x optical zoom and continuous 360° rotation, which lets you easily track moving objects. AXIS M5525-E provides both the magnified detail and the wide overview you need to stay on top of what is happening in your premises. WDR - forensic capture delivers great detail when the scene contains both bright and darker areas. The camera's exceptional light sensitivity means high-quality video even when it records in near-total darkness.
-
High flexibility
AXIS M5525-E is a universal camera for indoor or outdoor use, compatible with all Axis PTZ mounts. It offers two-way audio and four digital input/output ports for integration with other equipment. It also has three scene profiles to choose from:
-
Sharp images, low bandwidth
AXIS M5525-E features Axis Zipstream technology, which analyses the video stream in real time to identify areas of interest. These areas are compressed less than other areas, preserving important details at full image quality while reducing storage and bandwidth. The result is high-quality images and significant savings.
|
| General |
| Device type |
Network surveillance camera |
| Audio support |
Yes: Two-way audio capability, built-in microphone |
| Camera mounting type |
Surface mount |
| Connection technology |
Wired |
| Width |
16.5 cm |
| Depth |
16.5 cm |
| Height |
13.2 cm |
| Weight |
1.1 kg |
| Location |
Europe |
| Camera |
| Type |
Colour - day and night - pan / tilt / zoom - outdoor - dust-proof / weather-resistant |
| Digital video format |
MPEG-4, MJPEG, H.264 |
| Maximum digital video resolution |
1920 x 1080 |
| Digital zoom |
12 |
| Exposure range |
2 sec - 1/66500 sec |
| Minimum illumination |
0.45 lux - colour - F1.6 - 30 IRE
0.01 lux - B&W - F1.6 - 30 IRE
0.55 lux - colour - F1.6 - 50 IRE
0.01 lux - B&W - F1.6 - 50 IRE |
| Digital video capture resolution |
1920 x 1080, 320 x 180 |
| Frame rate (max.) |
25 frames per second |
| RAM |
512 MB |
| Flash memory |
256 MB |
| Functions |
Sharpness control, digital image freeze, white balance, saturation control, brightness control, contrast control, password protection, variable bitrate (VBR), sound detection, image overlay, exposure control, infrared filter, Forensic WDR, IP address filtering, exposure zone |
| Image Sensor |
| Type |
CMOS 1/2.8" |
| Lens Construction |
| Optical Zoom |
10 x |
| Focal Length |
4.7 mm - 47 mm |
| Focus Adjustment |
Automatic |
| Horizontal Field of View (degrees) |
6.7 - 61,8 |
| Vertical Field of View (degrees) |
3,8 - 37.2 |
| Pan |
| Range (degrees) |
360 |
| Speed (degrees/sec) |
Up to 150 |
| Tilt |
| Range (degrees) |
90 |
| Speed (degrees/sec) |
Up to 150 |
| Interfaces |
| Network Interface |
Ethernet 10Base-T/100Base-TX |
| Network Protocols |
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, IGMP, SSL, QOS |
| Expansion / Connectivity |
| Supported Memory Cards |
Card microSD |
| Miscellaneous |
| Included Accessories |
Mounting Kit |
| Compliant Standards |
EN 61000-3-2, EN 61000-3-3, EN55024, IEC 60529 IP66, EN 61000-6-1, ICES-003 Class A, EN 61000-6-2, FCC Part 15 B Class A, VCCI Class A, IEC EN60529, KN35, EN 55032 Class A, KCC KN32 Class A, IEC 62262 IK09, EN 62262 IK09 |
| Software / System Requirements |
| Included Software |
Windows Decoder 1-user license |
| Manufacturer Warranty |
| Service and Support |
Limited Warranty - 3 years |
| Environmental Parameters |
| Minimum Operating Temperature |
-20 °C |
| Maximum Operating Temperature |
50 °C |
| Relative Humidity (operating) |
15 - 100% |
