Description
USB4® is the first multi-port USB-C® hub to feature the latest USB4® controller from Intel®, offering compatibility with Thunderbolt™ and legacy USB™ interfaces.
You can connect up to two 4K displays to it in several ways:
1 DisplayPort + 1 HDMI
1 USB-C + 1 DisplayPort
1 USB-C + 1 HDMI
- One USB-C port supports up to 10Gbps data transfer and DP 1.2 support for 4K at 60Hz video output
- Two USB™ SuperSpeed+ 10Gbps ports (1 USB-C® and 1 Type-A)
- Power Delivery 3.0 offers up to 85W charging with USB-C power adapter
- Wide compatibility with various operating systems and devices
- Plug-and-play, no driver installation required
Connection: 1 - USB4 male
Ports: 1 - USB-C 3.2 Gen 2 (10Gbps) with DP 1.2 Support
1 - USB Type-A 3.2 Gen 2 (10Gbps)
1 - USB-C Power Delivery 3.0
1 - 4K HDMI
1 - DisplayPort 1.2
Video outputs: 1 - HDMI Female
1 - DisplayPort Female
1 - USB-C with DisplayPort alt mode
Supported displays: 2
Max. data transfer: 10Gbps
Max. frequency: 60 Hz
Max. resolution: 3840 x 2160
Input current: up to 3A
Input voltage: up to 20V
Output current: up to 4.25A
Output voltage: up to 20V
